| General specifications |
| LAN ports |
Standard |
IEEE 802.3 (10BASE-T/100BASE-TX/1000BASE-T) |
| Number of ports |
10 |
| Communication mode |
Auto negotiation |
| Connector type |
RJ-45 |
| MAC address |
Printed on top surface label |
| Polarity |
Automatic detection of straight/cross, or fixed at straight |
| Combo ports |
LAN ports |
IEEE 802.3 (1000BASE-T) 2 ports (use is mutually exclusive with SPF ports) |
| SFP ports |
SFP (Small Form-factor Pluggable) 2 ports (use is mutually exclusive with LAN ports) |
| SFP ports |
Standard |
IEEE 802.3z (1000BASE-SX/ 1000BASE-LX) |
| Number of ports |
2 |
| Console ports |
Standard |
RS-232C, USB 2.0 |
| Connector type |
RJ-45, USB mini-B (5-pin) |
| Data transmission speed |
9600 bit/s |
| Console port |
RJ-45(RS-232C), USB mini-B(5pin)(USB2.0): 9600 bit/s |
| Ports available for PoE power supply |
8 ports (1-8) |
| PoE standards |
IEEE 802.3at |
| Power supply system |
Alternative A |
| Maximum power supply |
Per port |
30 W |
| All ports |
240 W |
| microSD slot |
Standard |
microSD/microSDHC (microSDXC is not supported) |
| File System |
FAT/FAT32 |
| Number of slots |
1 slot |
| Indicators |
POWER, microSD, LAN port (LINK/ACT, SPEED), SFP port (LINK/ACT, SPEED) |
| MAC address |
Indicated in product label on top panel of unit |
| Operating environment |
Ambient temperature: 0–40 °C, Ambient humidity: 15–80%, non-condensing |
| Storage environment |
Ambient temperature: -20–50 °C, Ambient humidity: 10–90%, non-condensing |
| Power supply voltage, frequency |
AC100 ～ 240V, 50/60Hz |
| Maximum power consumption |
280 W |
| Dimensions |
W |
220 mm |
| H |
294 mm |
| D |
42.4 mm |
| Weight |
2.3 kg |
| Accessories |
Owner’s manual, power cord, power cord clamp, rubber feet |
